Eagle Vision Fully Adjustable Picatinny Torch, Laser, Mount

Eagle VisionSKU: IBP-60 + FAP 60

In stock


Eagle Vision Fully Adjustable Picatinny Torch, Laser, Mount

1 per Pack

This is the Micro Version of the fully adjustable windage and elevation mount, ideal for adding accessories and making them fully adjustable with ease.

We are very proud of this product as it’s development resolves some issues for shooters, who depend on the reliability of a solid mount.

Main benefits of using this mount:

1. Adjustability:
FULLY ADJUSTABLE, FORWARD or BACKWARD , ELEVATION, WINDAGE, HEIGHT ADJUSTMENT, that allows the Accessoris to move vertically and horizontally along a guided path, and lockable in different positions, using 2x  screws on the side of this mount.

2. Longer range shooting:
Pair of this mounts can be instal under any Picatinny scope mount and do elevation or hight adjustments for long range before running out of adjustment on the turrets
is the ability for users who need to reach out further but are restricted by their current mounting system.
By keeping the front mount at it’s lowest and elevating the rear mount to the highest point you can zero in your gun far beyond, without using the clicks on your turrets, hence keeping the optical centre of your scope intact.

3.Using Single can fully adjustable Windage/elevation, using pair can be only elevating

Technical information for the new mount:

Length: 60mm
Profile height from bottom of the mount to middle of the top picatinny rail, 21mm.
Total height: 30.30mm
Adjustable Height: 4.5mm
Weight: 81 grams

Product includes:

1x Infinity picatinny Torch mount
3 x Allen keys, (two different sizes)
3 x side screws
2 x m5 spring screw

Torque calculation:
Adjustable side screws maximum torque,
53-71 inch-pound force to 6-8 NM Newton Meters.
Picatinny nuts maximum torque,
53-71 inch-pound force to 6-8 NM Newton Meters.
